2D Session 1 Practical

PRACTICAL WORKSESSION

  • Practical Sessions contain sketches or drawings which must be completed, then uploaded by you.
  • This practical drawing must preferably be completed then uploaded after completing Tutorial Session 1 and before proceeding to Tutorial Session 2.
  • Upload your drawing using the facility provided.
  • Your uploaded drawing is not automatically graded, however your Educator or Course Instructor will communicate with you if necessary.
  • A total of 5 Points will be added to your scoresheet for uploading this Practical exercise.

DESIGN BRIEF

  • Draw the sketch using methods instructed during Tutorial Session 1.
  • Fully dimension the drawing using all appropriate dimensions.
  • Use good design judgement and  improvise as accurately as possible for missing dimensions.
